Half Adder & Full Adder

Half Adder (HA)

C = AB S = AB’ + A’B = A XOR B

Half Adder: Digital logic circuit that performs binary addition of two single-bit binary numbers.

Has two inputs, A and B, and outputs SUM (LSBit) and CARRY (MSBit).
Can be implemented with basic gates like XOR and AND gates.

Creating a Half Adder

Behavior:

\begin{align*} \begin{align*} & 0 \\ + & 0 \\ = & 00 \end{align*} \qquad & \qquad \begin{align*} & 0 \\ + & 1 \\ = & 01 \end{align*} \\ \begin{align*} & 1 \\ + & 0 \\ = & 01 \end{align*} \qquad & \qquad \begin{align*} & 1 \\ + & 1 \\ = & 01 \end{align*} \end{align*}

Rewritten as a truth table:

A	B	Carry	Sum
0	0	0	0
0	1	0	1
1	0	0	1
1	1	1	0

Observations:

Carry functions like AB (AND)
Sum functions like A’B + AB’ (XOR)

Note: Remember to think of the logic gates as minimum and maximum functions!

Full Adder (FA)

C=AB+AC+BC=Majority Gate S=A XOR B XOR C=A’B’C + A’BC’ + AB’C’

Full Adder: Like a half adder, except it adds 3 bits instead of 2 bits.

Creating a Full Adder

Behavior:

\begin{align*} \begin{align*} & 0 \\ + & 0 \\ + & 0 \\ = & 00 \end{align*} \qquad & \qquad \begin{align*} & 0 \\ + & 0 \\ + & 1 \\ = & 01 \end{align*} \qquad & \qquad \begin{align*} & 0 \\ + & 1 \\ + & 0 \\ = & 01 \end{align*} \\ \begin{align*} & 0 \\ + & 1 \\ + & 1 \\ = & 10 \end{align*} \qquad & \qquad \begin{align*} & 1 \\ + & 0 \\ + & 0 \\ = & 01 \end{align*} \qquad & \qquad \begin{align*} & 1 \\ + & 0 \\ + & 1 \\ = & 10 \end{align*} \\ & & \begin{align*} & 1 \\ + & 1 \\ + & 1 \\ = & 11 \end{align*} \end{align*}

Truth Table:

A	B	C	Carry	Sum
0	0	0	0	0
0	0	1	0	1
0	1	0	0	1
0	1	1	1	0
1	0	0	0	1
1	0	1	1	0
1	1	0	1	0
1	1	1	1	1

Observations:

Sum functions like a 3-input XOR (XOR3).
Carry functions like a majority function

Majority Function: A 2/3 of the bits must be 1 to output 1.
AB + AC + BC

Positional Value

In a positional system, the value of a digit is the digit \times place value. The total value is the sum of these products.

Ripple Carry Adder

To denote positional value in binary, we can chain the carry-bit into another addition procedure.

a 3-bit RCA (a + b)

Step-by-step addition of two 3-bit numbers:

a_0 + b_0 are added by the rightmost FA. The carry bit (c_0) is carried over to the next calculation.
a_1 + b_1 + c_0 is done by the middle FA. The carry bit (c_1) goes to the next calculation
a_2 + b_2 + c_1 is done by the leftmost FA. The carry bit is the MSBit.

Variation with HA: You could also do step 1 with a HA to save electricity and improve speed, but using a FA makes the design cascadeable.
e.g., you can create a 6-bit adder by connecting two 3-bit adders; or a 9-bit adder using three 3-bit adders, etc.

Variation: Subtractor

Recall: To get the two’s complement (negative) of a binary number, you need to apply NOT to every bit and do +1

We can NOT b and put 1 into the first FA to do a + (-b)

Example: Thinking Backwards

This is an incrementer:

(a+1)

Q: What if we want to do (a-1)?
A: We just find a + (-1) (add the two’s complement of 1 to a.
Let’s find the two’s complement of a 3-bit representation of 1 to find pattern.
001_2 = 1_{10}
NOT
(001_2)' = 110_2
+1
\begin{align*} &110 \\ +&001 \\ =&111 \end{align*}
Thus, 111_2 = -1_{10}
Note: Alternatively, we could’ve used the shortcut of flipping all bits left of the rightmost 1 bit (CS2640 - Two’s Complement).

Thus, a decrementer looks like this:

Example: Adder and Subtractor Combo

To combine the adder and subtractor, we’ll need to use this property of XOR:

XOR can be a buffer or a NOT gate

Using this switch technique, we can toggle between adding A+B and adding A+(-B).

Variations of HA and FA

Half Adder Plus (HA+)

C=A+B S=AB+A’B’=A XNOR B

Half Adder Plus: Like a half adder, except it does A+B+1 rather than A+B.

Can be implemented with OR and XNOR.

A	B	C	S
0	0	0	1
0	1	1	0
1	0	1	0
1	1	1	1

Half Adder Minus (HA-)

C=(A+B)‘ S=AB+A’B’=A XNOR B

Half Adder Minus: Like a half adder, except it does A+B-1 rather than A+B.

Can be implemented with NOR and XNOR.

A	B	C	S
0	0	1	1
0	1	0	0
1	0	0	0
1	1	0	1

Half Adder Minus Minus (HA- -)

C=(AB)‘ S=AB’+A’B=A XOR B

Half Adder Minus Minus: Like a half adder, except it does A+B-2 rather than A+B.

Can be implemented with NAND and XOR.

A	B	C	S
0	0	1	0
0	1	1	1
1	0	1	1
1	1	0	0

Full Adder Minus Minus (FA- -)

Carry = (AB + AC + BC)‘; Sum = A XOR B XOR C = A’B’C + A’BC’ + AB’C’ + ABC

Fall Adder Minus Minus: Like a full adder, except it does A+B+C-2 rather than A+B+C.

Can be implemented with Minority Gate and XOR.

Note: A minority gate is just the NOT of a majority gate.

A	B	C	Carry	Sum
0	0	0	1	0
0	0	1	1	1
0	1	0	1	1
0	1	1	0	0
1	0	0	1	1
1	0	1	0	0
1	1	0	0	0
1	1	1	0	1

Note: You can’t make FA+ or FA++ because there aren’t enough bits to represent 4_{ 10 }

Note: You can’t make FA- we can’t represent -1_{10} and 2_{10} without mixing the signed and unsigned numbers (the meaning of the MSBit becomes vague).
