We know that CFLs are closed under the regular operations (closure properties)
e.g., union, concatenation, and star of CFLs are CFLs.
Q: But, how can we prove it?
A: We can construct CFGs or PDAs for them.
Suppose two CFLs, S_1 and S_2
Union:
S \to S_1 | S_2 \\
Concatenation:
S \to S_1 S_2
Star:
S \to \epsilon | S S_1
When is a Language Context-Free?
When a variable in a different context yields a different result.
aV \to ab \\
Vc \to de
For this class, since we don’t know any formal method, we roll with reasoning about the PDA’s stack.
Technically, there is a pumping lemma for telling if a language is context-free; like how we used pumping lemma to tell if a language was regular; except we didn’t learn it.
If the language cannot be done without reaching deeper into the stack, like:
\{a^m b^n c^m d^n\} (can’t compare a and c)
If language has no stack pattern, like:
\{ a^n b^{2n}\} (infinite counting)
tl;dr, If you can’t describe the language as “pop as like this and pop bs like that”, it’s not context-free.
Examples
\{ a^n b^{n+2} a^n \}
The last a cannot be
Are all NFAs PDAs?
Yes, just ignore the stack (e.g., a, \epsilon \to \epsilon)
Final Diagram
A turing machine would wrap around PDA. It can do a lot of things, like moving the tape left and right.
But for this course, we just need to know:
Can the language be represented by NFA?
Is this context-free? (without proof)
The proof, which we didn’t learn, is like doing several pumping lemma proofs.
