Pushdown Automata

On Pushdown Automaton v. Finite Automaton:

A finite automaton reads a single tape of input in one direction.

A pushdown automaton also reads an input tape, but it also has an additional tape that it can read and write to.

Stack: A PDA can write and read symbols to the stack.

• Writing a symbol “pushes down” all other symbols on the stack.
• Reading a symbol removes it from the top, moving all the symbols back up.

Push In Notation (r,o \to i)

Example: r,o \to i

• This transition means we can go from state 1 to 2 by:
  • Reading r,
  • Popping out “o” from the stack, and
  • Pushing in “i” to the stack.

Formal: Let \Gamma be an alphabet, then:

• o, i \in \Gamma_\epsilon = \Gamma \cup \{ \epsilon \} - (because we can also push and pop epsilon)

Example: Marking End of Stack

• We like to push $ to the stack at the start to indicate the end.

Examples

Example: Simple PDA

• Q: Write a PDA that reads a string of { a^n b^n }
• A: Our solution will be to push “0” every time we read “a” and pop “0” every time we read “b”, and using a sentinel value to verify |a| = |b| = n eps
• We use transitions to limit the strings we can accept.
• Notice how we never counted the variables, we just used the simplest hardware

Example: Write a PDA that accepts { a^n b^{3n} }

Example: Write a PDA that accepts { a^n b^{3n+1} }

• In the above photo, we can replace the \epsilon, \epsilon \to \epsilon between the a and b loop with b, \epsilon \to \epsilon to require +1 b.

Example: Write a PDA that accepts { a^n b^{m} | m \ge 3 }

• Q: We can rewrite this as { a^n b^{3n} b^k | k \ge 0 }
• A: Use the PDA from { a^n b^{3n} }, but put a self-loop on the accepting state that is b, \epsilon \to \epsilon

What We Need to Know

Formal Definition

A pushdown automaton is a 6-tuple (Q, \Sigma, \Gamma, \delta, q_0, F) where:

1. Q: Set of states
2. \Sigma: Input alphabet
3. \Gamma: Stack alphabet.
4. \delta: Q \times \Sigma_\epsilon \times \Gamma_\epsilon \to P(Q \times \Gamma_\epsilon) is transition function
5. q_0 \in Q: Start state
6. F \subseteq Q

Q, \Sigma, \Gamma, and F are finite.

Generic Grammar to PDA

Example

Suppose the grammar

S \to a^2 S b | \epsilon

We’ll write the parse tree:

We will begin copying the parse tree onto a PDA’s stack tape now:

From layer one we have:

a	a	S	b	$

When we read a terminal, we want to pop it off the stack. e.g.,

• a, a \to \epsilon
• b, v \to \epsilon to When we read a variable, we have to expand it.
• In this case, after reading two a’s, S can either be expanded into aaSb or \epsilon

Suppose we’ve read two as and now have to expand S.

S	b	$

1. Pop S (\epsilon, \epsilon \to S)
2. Push b (\epsilon, b \to \epsilon)
3. Push S (\epsilon, S \to \epsilon)
4. Push a (\epsilon, a \to \epsilon)
5. Push a (\epsilon, a \to \epsilon)

The PDA so far looks like:

1. Push $
2. Push S
3. Major Loop:
   1. Pop S
   2. Push b
   3. Push S
   4. Push a
   5. Push a
4. Read a, pop a (x2)
5. Major Loop OR just pop S and push epsilon.

Finally, to account for b, we just read the right number of bs and then pop $ to reach the accepting state.

Steps

1. Push $ and start variable
   • This goes to a large loop state.

2. \forall rule: A \to w:
   • pop A, and push w^R (push W in reverse)

3. \forall t \in \Gamma:
   • add t, t \to \epsilon

4. \epsilon, \$ \to \epsilon from loop to accept.

More Examples

A

S \to aTb|b \\ T \to Ta|\epsilon

• Correction: \epsilon, T\ to a should be T, T\ to a

B

a^i b^j c^k | i,j,k \ge 0 \text{ and } i = h \lor i = k

Divide and conquer.
